Impeller : CI.
Inbuilt Thermal.
Overload Protector.
Wet type squirrel cage induction motor.
Mechanical Seal : Ceramic & Graphite, Self lubricated double ball bearing Inbuilt TOP.
| HP | Head range (MTS) | Discharge (LPM) |
|---|---|---|
| 3.0 HP and 5.0HP | 6 to 42 | 186 to 1333 |
| 0.5 HP and 1.0 HP (Special Pumps) | 9 to 28 | 50 to 201 |
- Designed to operate under wide voltage fluctuations.
- No need to separate Foot valve.
- The foundation is not required.
- Available in single phase & three phase.
- Swimming pools, Deep wells.
- Sprinkler, Drip Irrigation.
- Agriculture.
| S.NO | HP | KW | TYPE | PipeSize (mm) | Head in Meters (Single Phase) | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Discharge in LPM |
6 | 9 | 12 | 15 | 18 | 21 | 24 | 27 | 30 | 33 | 36 | 39 | 42 | |||||
| 1 | 3.0 | 2.2 | BC1 | 80 | 1040 | 850 | 692 | 463 | ||||||||||
| 2 | 3.0 | 2.2 | BC3 | 65 | 900 | 840 | 780 | 672 | 540 | |||||||||
| 3 | 3.0 | 2.2 | BC4 | 50 | 620 | 618 | 612 | 584 | 534 | 420 | 198 | |||||||
| 4 | 3.0 | 2.2 | BC5 | 50 | 462 | 438 | 420 | 390 | 354 | 318 | 282 | 240 | 186 | |||||
| 5 | 3.0 | 2.2 | BC6 | 40 | 395 | 392 | 387 | 381 | 375 | 348 | 321 | 294 | 252 | 210 | 162 | 72 | ||
| 6 | 5.0 | 3.7 | BC1 | 80 | 1333 | 1258 | 1161 | 1058 | 873 | 682 | 349 | |||||||
| 7 | 5.0 | 3.7 | BC3 | 65 | 1040 | 1020 | 949 | 888 | 820 | 712 | 580 | 414 | ||||||
| 8 | 5.0 | 3.7 | BC4 | 50 | 895 | 885 | 875 | 810 | 718 | 622 | 540 | 360 | ||||||
| 9 | 5.0 | 3.7 | BC5 | 50 | 580 | 576 | 550 | 514 | 486 | 468 | 443 | 400 | 375 | 346 | 288 | 246 | ||
| 10 | 5.0 | 3.7 | BC6 | 40 | 490 | 470 | 456 | 449 | 440 | 434 | 419 | 400 | 370 | 344 | 314 | 281 | 255 | |
